Tampa International Airport

As a result of a RFP from architects Gresham Smith & Partners, on behalf of their client Hillsborough County Aviation Authority, KDM were selected to produce two models showing the existing and proposed development of Tampa International Airport.  The larger model with Grey aircraft is 1" = 30' (1:360) the smaller with white aircraft is 1" = 60' (1:720).  Both models are 14' in length, the 1:360 is 8' wide whilst the 1:720 is 7' tapering to 6'. The tapered (West) side is slightly radiused to flush fit against an existing construct.

Both are lit using remotely controlled (RF) 75 watt LED units and over 2500 individually installed and routed .75mm fiber optic strands.

The models are on permanent public display in the new HCAA gallery located on level 3 of the main terminal building.



Photos below taken during installation.





Photos below taken during construction





Charlotte Douglas International Airport, NC.

Section through terminal building, roadway and parking garage showing proposed revision to existing facility.

Presented on pedestal with clear acrylic museum quality cover for permanent display in arrivals concourse.

Illuminated throughout on demand.





Stinson Municipal Airport, ATCT, San Antonio, Texas for AJT Engineering, Cocoa, FL. Scale 1:48 (1/4 inch = 1 foot)





Orlando International Airport FAA control tower

At 1:96 scale, this model stands four feet tall. It was built from original construction drawings supplied by our client Hensel Phelps Construction.

The model was displayed during construction of the real tower in Orlando and has since been presented to the FAA for display in their Atlanta GA. headquarters.

The following five photographs are a mix of the model and the actual finished tower.

MCOTWR1.jpg (37716 bytes)   MCOtwr12.jpg (73173 bytes)   MCOtwr18.jpg (75591 bytes)   MCOTWR2.jpg (49162 bytes)   MCOtwr22.jpg (85593 bytes)

Ranger Jet Center, FBO, Kissimmee Municipal Airport

RFBO13.jpg (41247 bytes)   Ranger FBO2.jpg (49727 bytes)  Ranger FBO3.jpg (55409 bytes)   Ranger FBO4.jpg (36609 bytes)

Embry Riddle Aviation University Administration Building.  For Architects Gresham Smith & Ptnrs.
